Floating machine E9

The Elematic floating machine E9 is designed to smoothen precast wall panels. It is suitable for all types of wall production lines.

The floating machine E9 is an easy to use, mechanized method for smoothing precast product surfaces. The machine features a rotating mechanism with a rotating steel disc or floating blades that level the surface of the panel.

Floating machine E9-900

Available as half-portal, portal and bridge types
Diameter of the floating disc 1100 mm
Rotating speed max. 100 1/min

The speed is adjustable using inverter technology, and the floating force and position of the floating blades are mechanically adjustable.

The machine is controlled with a portable radio control device. All machine functions are electrical.

COMPOSITION

The Elematic floating machine is available in several variants: bridge-, half portal or full portal type. The type and span of the machine can be chosen according to production hall layout.

BUILT-IN SAFETY

The floating machine E9 is delivered with comprehensive operator, maintenance and safety manuals in the required language.

OPTIONS

Power supply current conductor rails

Traveling rails

Benefits

  • Suitable for all types of production lines

  • Easy to use
